Writing SQL Queries against Excel files
(Excel SQL)
Follow
 Note: QuerySurge 6.3 and below connect to Excel using Java's built-in
JDBC/ODBC bridge along with the Microsoft's Excel ODBC driver. This article
describes the query syntax for this JDBC/ODBC bridge-based approach. Since
QuerySurge 6.3, QuerySurge has shipped with its own proprietary JDBC driver for
Excel. Users are strongly urged to use this all-Java JDBC driver for Excel data, as Java's
JDBC/ODBC bridge has been removed in Java 8 and above. Details for the new
QuerySurge JDBC Driver for Excel are available in this article.
 Note: Connection to Excel via Java's builtin ODBC/JDBC bridge feature (on which
this connection depends) is being deprecated starting with the QuerySurge 6.4 release,
since Java has removed the bridge feature. While QuerySurge 6.4 is backwards-
compatible for your existing Excel queries, you should start planning to move your
existing queries to the QuerySurge Excel JDBC Driver. The current date for sunset of
backwards-compatibility is October 31, 2019. For more information, see our FAQ.
Microsoft Excel handles SQL via its own SQL dialect. The tutorial below provides an
introduction to the syntax for SQL querying against Excel files, focusing on common
approaches when pulling data from Excel as a QuerySurge Source or Target.
Excel SQL Examples
1. Simple SELECT *. Create a query that selects all rows and columns from the Excel
file.

SELECT * FROM [SALES$];

In this example, the query fetches all rows and columns in the SALES sheet. Note
the syntax for the table name in the FROM clause is: [SHEETNAME$] (using
enclosing square brackets and a dollar sign after the sheet name). You can query
against different sheets in an Excel file using this syntax.

2. Simple SELECT. Create a query that selects specific columns from the Excel file.

SELECT [QUANTITY],[NAME],[PRICE] FROM [SALES$];

In this example, we specify the columns we would like the query to return. Note the
syntax for the column names in the SELECT clause is: [COLUMN1],
[COLUMN2].

https://querysurge.zendesk.com/hc/en-us/articles/205766136-Writing-SQL-Queries-against-Excel-files-Excel-SQL-/subscription.html
https://querysurge.zendesk.com/knowledge/articles/360007800591/
https://querysurge.zendesk.com/hc/en-us/articles/360020869591
3. WHERE clause. Use a WHERE clause in your query to filter your Excel data.

SELECT [QUANTITY],[NAME],[PRICE] FROM [SALES$]
 WHERE [SALE_ID] >= 23 AND [SALE_ID] <= 28;
In this example, we limit our result set to records whose [SALE_ID] is >= 23 and <
28. The syntax for column names in the WHERE clause uses square brackets, as we
saw previously: [COLUMN1].

4. Cell Ranges. Limit your query to a specific cell range.

SELECT [QUANTITY],[NAME],[PRICE] FROM [SALES$A1:E101];

In this example, we do not impose any limitations on the values themselves.
However, we direct the query to look only at a Range of cells (A1 through E101).
Note that the cell range is specified after the dollar sign in the table name, using the
colon between the first cell and the final cell in the range.

5. Filter by date syntax. Create a query that filters by date with an ORDER BY


a. SELECT [SALE_ID],[SALE_DATE],[QUANTITY],[NAME],[PRICE]
FROM [SALES$A1:E101]
WHERE [SALE_DATE] = #12/6/2003#
ORDER BY [SALE_ID];

b. SELECT [SALE_ID],[SALE_DATE],[QUANTITY],[NAME],[PRICE]
FROM [SALES$A1:E101]
WHERE [SALE_DATE] BETWEEN #12/6/2003# AND #1/1/2008#
ORDER BY [SALE_ID];
In these examples, the query limits the result set to records where
the [SALE_DATE] is equal to 12/6/2003 (example a) or between 12/6/2003 and
1/1/2008 (example b). Note the syntax for specifying date values is #M/d/yyyy#,
using both leading and trailing hash symbols. Additionally, we order the records by
their [SALE_ID] in the ORDER BY clause. The syntax for column names in
the ORDER BY clause is (as before): [COLUMN1].

6. String functions: MID. Create a query using a string function in the WHERE clause.

SELECT [SALE_ID],[SALE_DATE],[QUANTITY],[NAME],[PRICE]
FROM [SALES$A1:E101]
WHERE [SALE_DATE] BETWEEN #12/6/2003# AND #1/1/2008#
 AND MID([NAME],1,4) = 'NYNY'
ORDER BY [SALE_ID];

In this example, we have demonstrated the use of the VBA MID() function.

A listing of String functions is at: https://msdn.microsoft.com/en-
us/library/dd789093.aspx.

7. Data Type Conversions. Create a query showing how to do a type conversion.

SELECT [ID],CLNG([OID]),[DESC],[SALE_DATE] FROM [PRODUCTS$];

The second column has a type conversion – to the LONG type.

VBA type conversion functions include the following:

Type Conversion
Function
Return Type (Java.sql.Types)
CBool(col_name) SMALLINT
CByte(col_name) SMALLINT
CDate(col_name) TIMESTAMP
CDbl(col_name) DOUBLE
CInt(col_name) SMALLINT
CLng(col_name) INTEGER
CSng(col_name) DOUBLE
CStr(col_name) VARCHAR
8.
Note: CDate() does not recognize newer date formats, such as the yyyy-MM-
ddTHH:mm:ss format. However, it does recognize the yyyy-MM-dd
HH:mm:ss format. You can use the REPLACE function to change the ‘T’ to a
space, to get a format that is recognized:
CDate(REPLACE([date_col], 'T', '')

9. Date formatting. Create a query formatting a date column.

SELECT FORMATDATETIME( [SALE_DATE], 1),
 FORMAT([SALE_DATE], 'yyyy-mm-dd')
FROM [SALES$]
WHERE [SALE_DATE] BETWEEN #12/6/2003# AND #1/1/2008#;

The FORMATDATETIME function has a set of fixed options for formatting, shown in
https://msdn.microsoft.com/en-us/library/dd789093.aspx
https://msdn.microsoft.com/en-us/library/dd789093.aspx
the following table.

Format Code Description
0
Display a date and/or time. Date parts are displayed in short date
format. Time parts are displayed in long time format.
1
Display a date using the long date format specified in your
computer's regional settings.
2
Display a date using the short date format specified in your
computer's regional settings.
3
Display a time using the time format specified in your computer's
regional settings.
4 Display a time using the 24-hour format (hh:mm).
10. If you need a more flexible set of formatting options, the FORMAT function takes a
format template string:
Format Code Description
d Display the day as a number without a leading zero (1 – 31).
dd Display the day as a number with a leading zero (01 – 31).
ddd Display the day as an abbreviation (Sun – Sat).
m
Display the month as a number without a leading zero (1 – 12). If m
immediately follows h or hh, the minute rather than the month is
displayed.
mm
Display the month as a number with a leading zero (01 – 12). If m
immediately follows h or hh, the minute rather than the month is
displayed.
mmm Display the month as an abbreviation (Jan – Dec).
mmmm Display the month as a full month name (January – December).
oooo The same as mmmm, only it's the localized version of the string.
y Display the day of the year as a number (1 – 366).
yy Display the year as a 2-digit number (00 – 99).
yyyy Display the year as a 4-digit number (100 – 9999).
11.
See https://msdn.microsoft.com/en-us/library/office/gg251755.aspx for a listing of
format options.

12. Number formatting. Create a query showing how to format a number.

SELECT [QUANTITY],[NAME],format([PRICE],'###.000')
FROM [SALES$]
WHERE [SALE_DATE] BETWEEN #12/6/2003# AND #1/1/2008#;

https://msdn.microsoft.com/en-us/library/office/gg251755.aspx
The [PRICE] column is formatted to three decimal places. Note that the formatting
code must be enclosed in single quotes, not double quotes. Note also that the format
function returns a string type, so if you want to do math with a formatted value,
you’ll have to cast it to a numerical type with a type conversion function. The table
below shows a variety of formattingexamples.

Format Explanation Example Output
0
Always display a digit including
leading/trailing 0; Rounds if necessary
Format(31.4159, '000.00000') 031.41590
0 - Format(31.4159, '00.000') 31.416
#
Display digit or for leading/trailing 0,
omit the 0 digit; Rounds if necessary
Format(31.4159, '###.#####') 31.4159
# - Format(31.4159, '##.####0') 31.41590
% Fraction expressed as percent Format(0.4159, '##%') 42%
E- E+ Scientific notation Format(3.14159, '####E-##') 3142E-3
- + $ () Include a literal character Format(31.4159, '$####.00') $31.42
\ Escape a special character Format(0.4159, '0.###\%')
0.416%

13.

14. Conditionals. Create a query showing how to conditionally modify results.

In many SQL dialects, this is done with a CASE statement. In Excel SQL, this is
done with the IIf() function. The function signature is: IIf (expr,
truepart, falsepart). If expr evaluates to true, then truepart is
returned, otherwise, falsepart is returned. The following example returns the
string 'SPECIAL!' if the price is less than $1.00; otherwise it returns the actual
price.

SELECT [QUANTITY],[NAME],
 IIf([PRICE] < 1.00,'SPECIAL!',[PRICE])
FROM [SALES$]
15. Null Handling. Under some conditions, such as when a cell is has no data, Excel
returns a Null value. You can test whether a cell is null using
the IsNull(expr) IsNull() returns a Boolean true value (=-1) if the
argument is null, and a Boolean false (=0) if the argument is not null. A simple
example is:

SELECT IsNull([QUANTITY])
FROM [SALES$]

This function can be combined with the IIf() syntax to return a specific value in
cases where a null is found in a column, and the actual column value where the value
is not null. Note, in the following example, that the value that we return when we
find a null is the second argument – the truepart argument, because this is
returned when IsNull() returns true .

SELECT IIf(IsNull([PRICE]), 'NULL FOUND!', [PRICE])
FROM [SALES$]

For the following data, the query will return the price in the column for ID = 1, 2, 3;
for ID = 4, the query returns ‘Null Found!’.

ID PRICE
1 10.02
2 102.35
3 9424.23
4 Null Found!
