CHAPTER 14 491

With this in mind, let’s consider the following alkene:



While this molecule does possess some symmetry, you should avoid falling into the trap of calling it a
symmetrical alkene and erroneously deciding that the C=C double bond will not produce a signal. In fact,
the dipole moment for this C=C bond is expected to be quite large (because of the combined inductive
effects of the chlorine atoms. One vinylic position (the one connected to the two chlorine atoms) is more
electron-deficient (+) than the other vinylic position. As a result, this C=C bond is expected to produce a
rather strong signal in the IR spectrum.

Solutions
14.1.
(a) The CH bond is expected to produce the signal
with the largest wavenumber, because bonds to H
typically produce high-energy signals (due to the low
mass of the hydrogen atom). Among the remaining two
bonds, the triple bond is stronger than the double bond,
so we expect the double bond to produce the signal with
lowest wavenumber.



(b) Each of the bonds in this case is a single bond. The
CH bond is expected to produce the signal with the
larger wavenumber, because bonds to H typically
produce high-energy signals (due to the low mass of the
hydrogen atom).



14.2.
(a) This compound exhibits an sp2 hybridized carbon
atom that is connected to a hydrogen atom. As such, this
CH bond (highlighted) should produce a signal above
3000 cm-1 (at approximately 3100 cm-1).



(b) This compound has three sp2 hybridized carbon
atoms, but none of them are connected to hydrogen
atoms. And there are no sp hybridized carbon atoms.
Therefore, we do not expect a signal above 3000 cm-1.

(c) This compound has two sp hybridized carbon atoms,
but neither of them are connected to hydrogen atoms.
And there are no sp2 hybridized carbon atoms.
Therefore, we do not expect a signal above 3000 cm-1.

(d) This compound exhibits an sp2 hybridized carbon
atom that is connected to a hydrogen atom. As such, this
C-H bond (highlighted) should produce a signal above
3000 cm-1 (at approximately 3100 cm-1).



(e) This compound has two sp2 hybridized carbon atoms,
but neither of them are connected to hydrogen atoms.
And there are no sp hybridized carbon atoms. Therefore,
we do not expect a signal above 3000 cm-1.

(f) This compound exhibits an sp hybridized carbon
atom that is connected to a hydrogen atom. As such, this
C-H bond (highlighted) should produce a signal above
3000 cm-1 (at approximately 3300 cm-1).



14.3.
(a) One of the carbonyl groups (upper left) is not
conjugated, so it is expected to produce a signal at
approximately 1720 cm-1. The other carbonyl group
(bottom right) is conjugated to a C=C  bond, so it is
expected to produce a signal at approximately 1680 cm-1.



(b) One of the ester groups (bottom right) is not
conjugated, so it is expected to produce a signal at
